采用磁场定向控制技术、功率驱动级采用SVPWM调制、提供给电机三相矢量控制型正弦波电流输出;32位元的微处理器内核,系统表现出优异的运算能力和任务处理能力,可以同时处理转矩环、励磁环、速度环等高实时性要求的任务。
直接转矩控制,起步平滑,加速性能好,在中、高速度段加速性能尤其突出,近似燃油摩托车操控性能。矢量控制型正弦波电流输出转矩更平滑,充分抑制电机转矩波动而引起的低频噪音。
您的浏览器版本过低,为保证更佳的浏览体验,请点击更新高版本浏览器
以后再说X采用磁场定向控制技术、功率驱动级采用SVPWM调制、提供给电机三相矢量控制型正弦波电流输出;32位元的微处理器内核,系统表现出优异的运算能力和任务处理能力,可以同时处理转矩环、励磁环、速度环等高实时性要求的任务。
直接转矩控制,起步平滑,加速性能好,在中、高速度段加速性能尤其突出,近似燃油摩托车操控性能。矢量控制型正弦波电流输出转矩更平滑,充分抑制电机转矩波动而引起的低频噪音。
Specification: | |
Size | 100mm×60mm×25mm |
Rated Voltage | DC24V/DC36V |
Rated Power | 250W |
Low Voltage protection | DC21.5V(±0.5V)/DC31.5V(±0.5V) |
Current Limit | 12A(±0.5A)/15A(±0.5A) |
Standby Power Consumption | <2W |
Housing Materials | Aluminum |
Water Proof | IPX6 |
Motor Matching | Sensored Motor /Sensorless Motor |
Display Matching | LED Display/ LCD Display |
Functions &Features: | |
Super low noise | Reduce the motor torque ripple to minimum; achieve vehicle nois-e-free, vibration-free and comfortable riding feeling. |
High efficiency | Field oriented control(FOC)sine-wave driving technology allows hi-gher system efficiency, lower heat loss and longer riding mileage. |
Multiple Protections | Over-current protection,over-voltage/under-voltage protection, ov-er-heat protection, runaway protection, short-circuit protection, ph-ase wire disconnect protection, blockage protection. |
Auto-sleep | When parking for more than 10 minutes without any operation, th-e system auto-matically power off to save battery power. |
Flexible configuration | Parameter settings can be modified through USB interface with th-e computer, or through display. Parameter include current limit val-ue, low voltage protection value, sensor type, maximum speed, po-wer ratio etc. |
EN15194 | All the controller specifications and functions are 100% guarantee-d to pass the EN15194 test. |
